AI Extension
AI Extension
The AI Extension adds 4 more analog (or digital) inputs that are perfectly suited for various sensors and temperature sensors.
4 inputs (0-10 V) or 4 digital inputs
compact design: occupies only 2 positions
100% tuned for Loxone Miniserver
CE tested and certified More
Manufacturer: Loxone Electronic GmBHProduct code: 56231 Shipping and Payment
The AI Extension adds 4 more analog (or digital) inputs that are perfectly suited for various sensors and temperature sensors.
4 inputs (0-10 V) or 4 digital inputs
compact design: occupies only 2 positions
100% tuned for Loxone Miniserver
CE tested and certified More
Manufacturer: Loxone Electronic GmBHProduct code: 56231 Shipping and Payment
Universal helper
Take advantage of the 4 analogue inputs and integrate all 0-10V sensors into the Loxone Smart Home. Whether it's temperature sensors, pressure sensors or other 0-10V signals.
The analog inputs can also be used as digital inputs (24 V).
Certified and tested for your safety
The device meets all safety standards and is CE certified.
- 4 analogue inputs 0-10 V or 4 digital inputs 24 V DC
- Power: 24 V DC (9-28 V DC)
- Power dissipation: max. 392 mW
- Protection class: IP 20
- Operating temperature: 0-55 °C
- Operating humidity: 95% RH (non-condensing)
- Dimensions: 35.5 × 88 × 57 mm
