Bambu Lab AMS HT – Designed for High-Performance Materials
24 Colors / Multi-Material Support
-
Serial Connection of up to 4 AMS 2 Pro Units and 8 AMS HT Units – Supports up to 24 filaments in total.
Electromagnetic Air Valve
-
Enables fast filament drying and airtight storage.
Drying Temperature: 85 °C
-
Optimized for drying high-performance filaments.
Brushless Motor
-
Increases filament feeding speed by 60%.
Designed for Better Drying & High-Performance Filament Use
High-Temperature Drying
-
Drying temperature up to 85 °C, ideal for materials requiring higher heat.
Bypass Output
-
Dedicated outlet for flexible or brittle materials.
Fast and Intelligent Filament Drying
-
Electromagnetic Air Valve
Activates based on temperature and humidity for more efficient drying. -
Automatic Rotation During Drying
Spools rotate automatically for even drying. -
RFID Synchronization
Automatically sets drying parameters for official Bambu filaments—no manual adjustment needed. -
Dry / Wet (e.g., Bambu PET-CF)
Smart recognition and optimization.
Enhanced, Thoughtful Design
-
Ceramic Input Ports
Made to handle filaments with Vickers hardness up to 1200, significantly increasing durability. -
Overheat Protection
Precision temperature sensor and physical safety fuse ensure safe and accurate heating. -
Status Display
Clear digital screen for real-time monitoring of drying status.
Compatibility
-
The AMS HT is compatible with all Bambu Lab products.
AMS HT Specifications
| Item | Specification |
|---|---|
| Main Unit | |
| Dimensions | 114 × 280 × 245 mm |
| Weight | 1.21 kg |
| Enclosure Material | PC/PA |
| Flame Retardant Rating | UL 94 V-0 |
| Display | Shows real-time temperature, humidity, and remaining drying time |
| Printing | |
| Supported Filaments | PLA, PETG, ABS, ASA, PET, PA, PC, PVA (dry), BVOH (dry), PP, POM, HIPS, Bambu PLA-CF / PAHT-CF / PETG-CF / PLA/PETG support and AMS-compatible TPU |
| Bypass Output – Supported | TPE, standard TPU, Bambu PET-CF / TPU 95A, and other filaments containing carbon or glass fiber |
| Unsupported Filaments | PVA (wet), BVOH (wet) |
| Filament Diameter | 1.75 mm |
| Spool Dimensions | Width: 50–68 mm, Diameter: 197–202 mm |
| RFID Recognition | Supported |
| Filament Odometer | Supported |
| Drying | |
| Max Drying Temperature | 85 °C |
| Supported Filaments for Drying | PLA, PETG, PLA/PETG support, ABS, ASA, PET, PA, PC, PVA, BVOH, PP, POM, HIPS, Bambu PLA-CF / PAHT-CF / PETG-CF, AMS-compatible TPU |
| Active Moisture Removal | Supported |
| Rotating Drying Mode | Supported |
| Sealed Storage | Supported |
| Lid Open Detection | Supported |
| Real-Time Temperature & Humidity Monitoring | Supported (data viewable on display, printer, Bambu Studio, and Bambu Handy app) |
| Power | |
| DC Voltage | 24 V |
| AC Voltage | 100–240 V~, 50/60 Hz |
| Average Power Consumption | 150 W |
